PTO Gearbox ideal for agricultural applications

Speed Reducers: Model D101

Features include an aluminum housing, numerous input and output shaft configurations, including straight shaft with key, tapered shaft and agricultural PTO connection, 540 RPM or 1000 RPM, auxiliary hydraulic pump input or output, anti-engine rotation.

Typical Applications

Orchard Sprayer, PTO Driven Grain Vac, Utility Tractor, Farm Waste Pumping Systems


  • Ratios:1.19 : 1 through 4.5 : 1
  • Rotation:Anti-Engine
  • Max Horsepower:125 HP
  • Center Distance:6.0″
  • Overall Size:16.5″ H x 12.4″ W x 5.5″ D
  • Weight:60 lbs approx.
