• Broaching, Hobbing, Gear Grinding & More

    Prototype to Volume Precision Machining

    Rj Link’s manufacturing capabilities range from single piece prototype development to volume precision machining. We manufacture components and assemblies from a variety of raw materials including bar stock, plate stock, forgings and castings. We work with a variety of customer supplied materials including proprietary castings, specialty tubing and unique forgings. We can also provide additional services such as EDI, inspection, bar coding and more.



    In House Capabilities:

    • Vertical CNC Machining Centers: Max. 59″ length, 31.5″ width, 23″ height
    • Horizontal CNC Machining Center: 25″ cube size: Up to 45″ possible on a case by case basis
    • CNC Turning: Max. 24″ dia., max. 56″ length
    • Broaching: 50 ton & 5 ton, key min. 125″ and max 1″, Spline dia min .75″ and max 3.855″
    • Hobbing: 33.5″ dia., 2.5 DP, stock SAE & metric hobs
    • CNC Crown Hobbing: 14″ dia., 4 DP
    • Shaping: 36″ dia., 6″ max. gear face, 3.5 DP
    • Gear Shaving: 1″ thru 12″ dia., 4 thru 16 DP, Crown Shaving
    • Tooth Pointing/Tooth Rounding: Up to 16″ diameter
    • Gear Grinding: Up to 15.74″ diameter. AGMA class 5 per the new AGMA 2015 inspection standard. Considered AGMA class 12 per the old AGMA 2000-A88 standard
    • Assembly & Test Capabilities



    Services Offered:

    • Material Certifications
    • Heat Treat Certifications
    • Inspection Data
    • EDI
    • Solidworks Pro/E Solid Modeling



    Inspection Capabilities:

    • Coordinate Measuring Machine: X-Axis 27″, Y-Axis 40″, Z-Axis 24″
    • CNC Gear Inspection: Dia. 11.5″, length 23.5″, 550 lbs. load
    • 14″ Optical Comparator
    • Micrometers: Up to 30″ O.D., 36″ I.D.
