Rj Link’s manufacturing capabilities range from single piece prototype development to volume precision machining. We manufacture components and assemblies from a variety of raw materials including bar stock, plate stock, forgings and castings. We work with a variety of customer supplied materials including proprietary castings, specialty tubing and unique forgings. We can also provide additional services such as EDI, inspection, bar coding and more.
In-House Capabilities:
- Vertical CNC Machining Centers: Max. 59″ length, 31.5″ width, 23″ height
- Horizontal CNC Machining Center: 25” cube size: Up to 45″ possible on a case by case basis
- CNC Turning: Max. 24” dia., max. 56” length
- Broaching: 50 ton & 5 ton, Key min. 125″ and max 1″, Spline dia min .75″ and max 3.855″
- Hobbing: 33.5” dia., 2.5 DP, stock SAE & metric hobs
- CNC Crown Hobbing: 14” dia., 4 DP
- Shaping: 36” dia., 6” max. gear face, 3.5 DP
- Gear Shaving: 1” thru 12” dia., 4 thru 16 DP, Crown Shaving
- Tooth Pointing/Tooth Rounding: Up to 16” diameter
- Gear Grinding: Up to 15.74″ diameter. AGMA class 5 per AGMA 2015 inspection standard. Previously AGMA class 12 per AGMA 2000-A88 standard.
- Assembly & Test Capabilities
Engineering Support:
- Custom Gearbox Design & Build Services
- Gearbox Repair & Remanufacturing
- Finite Element Analysis (FEA)
- Prototyping & Validation Services
- Gear Sizing Software & Analysis
- Fixture & Tooling Design
- Process Design
- PPAP’s (Preproduction Approval Process)
- Program Management
- Reverse Engineering
- Technical Documentation Support
- Inspection-Coordinate Measurement Machine (27 in. x 40 in. x 24 in.)
- Inspection- CNC Gear Inspection (Dia. 11.5 inc. x length 23.5 in.)
